MDF inwall kit (CORE160/RE2060/DC1000)
CORE160
Active artcore loudspeaker, 6", rectangular







Description
This built-in speaker is one of the most indispensable elements of the Artcore system. You can find out how this system works on the previous pages. The CORE160 is an active built-in speaker that comes from the well-known Intiimi line. With a frameless grill of barely 1 mm and a thickness of just under 5 mm, it makes quick work of today’s standards. The titanium driver with neodymium magnet and patented® suspension, together with the advanced separation filter, create a magnificent sound experience. The CORE160 is driven by a double amplifier: 20 W (tweeter) + 70 W (woofer).
Not only is the CORE160 active, you can also use it both wired and wirelessly. In both cases, you control it via the Artcore app. This forms the dashboard with ser-vices such as Spotify, Vtuner, etc. This allows you to effortlessly cre-ate a flexible multi-room system.
Specifications
Reference | CORE160 |
Range | < 50m² |
Systeem | 2-way coaxial |
Frequency range | 55 Hz - 19,5 kHz |
Dimensions | 295 x 205 x 85 mm |
Weight/piece | 1,9 kg |
Power supply | 24V - 120W DC |
Composition | ABS / aluminium grill |
Dimensions cut-out | 270 x 180 mm (Ø) |
Power | 20 + 70 W |
Options | acoustic kit (KITRE3) |
Woofer characteristics | 6” neodymium |
Tweeter characteristics | 1” directable neodymium titanium dome |
Multiroom feature | yes |
Specific References
Reference | CORE160 |
ean13 | 5420020105564 |
Appurtenance
